Features and Benefits
- Frequency Range: 100.0MHz
- Supply Voltage: 5.0V
- Steady Current: 30mA(max.)
- Output Waveform: Sinewave
- Frequency Stability vs. Operating Temperature: ±0.5ppm
- Aging: ±1ppm(first year)
- Phase Noise @ 1kHz : -125dBc/Hz
- Operating Temperature: -40°C to +85°C
- Size: 15.0 x 9.0 x 5.0mm(Max)
Typical Applications
- Synthesizers
- SATCOM System
- Portable Applications
